Aftakelement - 1-weg

Coax Splitter - 1-Weg,

Type: Satelliet Aftakelement,
Ingang: F-Connector Female,
Uitgang: 2 x F-Connector Female,
Aftakdemping: 6 dB,

1-Weg tap 6 dB geschikt voor satelliet toepassingen.

Insertion 5-40 MHz: 3.5 dB
loss 40-450 MHz: 3.0 dB
(IN-OUT) 470-860 MHz: 3.5 dB
(IN-OUT) 950-1750 MHz: 5.0 dB
(IN-OUT) 1750-2400 MHz: 6.0 dB

TAP LOSS
(IN-TAP) 5-2050 Mhz: 6.5 ±1.5 dB
Direction 5-40 MHz: 18 dB
loss 40-450 MHz: 20 dB
(TAP-OUT) 470-860 MHz: 20 dB
(TAP-OUT) 950-1750 MHz: 16 dB
(TAP-OUT) 1750-2400 MHz: 16 dB
Return 5-40 MHz: 12 dB
loss 40-450 MHz: 14 dB
loss 470-860 MHz: 12 dB
loss 950-1750 MHz: 10 dB
loss 1750-2400 MHz: 10 dB
